Hospitality Pico Privacy Low Voltage Wired
Purpose-built guestroom privacy control for myRoom XC systems, enabling guest-controlled make-up-room and do-not-disturb request management.
Configure
Product Details
Overview
Purpose-built for in-room privacy management, this specialized Pico control empowers guests to communicate service preferences through myRoom XC systems. Two dedicated buttons allow guests to request make-up service or activate do-not-disturb status, with integrated LED indicators providing immediate visual confirmation in green for service requests and red for privacy mode. Low-voltage QS wiring ensures safe, reliable operation while the tamper-resistant wallplate snaps on without visible fasteners to preserve refined room aesthetics. Fixed-function engravings with internationally recognized privacy icons ensure intuitive operation regardless of language, reducing guest confusion and front desk inquiries. Directly integrated with myRoom XC infrastructure, this privacy control enables real-time status updates to housekeeping staff and property management systems.
- Durable precision-molded polymer construction available in satin Matte Arctic White and Matte Black finishes to complement guestroom interior design
- Two dedicated buttons provide clear, separate control for make-up-room service requests and do-not-disturb privacy preferences
- Large rectangular buttons with generous spacing provide confident operation for all guests, even in low-light conditions
- Integrated LED indicators offer immediate visual feedback, displaying green for active service requests and red for privacy mode
- Fixed-function engravings with internationally recognized privacy icons ensure intuitive operation for guests of all languages
- Direct integration with myRoom XC systems through QS low-voltage wiring enables real-time communication with property management
Optional custom text or icons
myRoom XC
- 2 Buttons
- Mounts easily in any 1-column or 2-column Lutron Pico faceplate (not included)
Specifications & Documents
General Specifications
Keypad Type
Wired
System Compatibility
myRoom XC
Button Configuration & Count
2 Buttons
Engraving Options
Standard Engravings
Connectivity
Connection Type
Wired
RF Frequency & Range
Low-voltage type IEC PELV/NECR Class 2 wiring connects wallstations and other devices on the QS link to the Lutron myRoom Guestroom Control Unit
Dimensions Specifications
H × W × D
H 3.5 in x W 3.5
Electrical Specifications
Operating Voltage
Operating Voltage: 24–36 V- (SELV/PELV/NECR Class 2)
Certifications Specifications
Environmental Rating
Indoor use only
Safety (UL, cUL)
0 °C to 40 °C (32 °F to 104 °F)
Warranty
Limited Warranty
