HomeWorks seeTouch RF Tabletop Keypad
The ultimate tabletop keypad platform featuring raised curved buttons, portable wireless operation, and unmatched customization.
Configure
Product Details
Overview
Setting the standard for customizable control, seeTouch RF tabletop keypads deliver unparalleled flexibility through the most comprehensive configuration options in the Lutron portfolio. The versatile design functions equally well wall-mounted in fixed locations, placed on nightstands and coffee tables, or carried as a handheld remote, adapting to how you live and work. Six configurations ranging from 5-button to 15-button layouts with various raise/lower arrangements accommodate simple room control or whole-home management from any location. The signature raised, curved buttons with upward-angled engraving maintain the exceptional seeTouch ergonomics, while the wake-up-and-activate feature ensures single-press operation when battery powered. Dual power options include DC adapter for continuous operation or two AAA batteries with intelligent power management that automatically shuts off backlighting during periods of inactivity. Each keypad features custom engraving for personalized button identification, and is engineered for seamless integration with HomeWorks control systems.
- Available in architectural finishes to complement any residential interior design
- Six configurations including 5, 10, and 15 button layouts with master or column raise/lower options
- Triple mounting versatility allows wall installation, tabletop placement, or handheld use
- Flexible power options with DC adapter for continuous use or AAA batteries for portable operation
- Field-changeable button kits with custom engraving allow complete reconfiguration without rewiring
- Clear Connect RF ensures reliable HomeWorks communication
Optional custom text or icons
HomeWorks
- Up to 15 buttons with raise lower
- Mounting bracket included for optional wall mount applications
Specifications & Documents
General Specifications
Keypad Type
Wireless
System Compatibility
HomeWorks
Button Configuration & Count
Up to 15 buttons with raise lower
Engraving Options
Optional custom text or icons
Status Indicator
Two status LEDs
Connectivity
Connection Type
wireless
QS Link Wire Specifications
HomeWorks QS RF seeTouch Tabletop Keypads communicate with the system through Radio Frequency (RF) and must be located within 30 ft (9 m) of an RF hybrid repeater
Dimensions Specifications
H × W × D
H 3.25 in x W 3.6 in x D 1 in
Electrical Specifications
Operating Voltage
2 AAA alkaline (included) 1.5 V each
Certifications Specifications
Environmental Rating
Indoor use only
Safety (UL, cUL)
Ambient operating temperature: 32 °F to 104 °F (0 °C to 40 °C), 0% to 90% humidity, non-condensing
Warranty
8 years against defects in materials/workmanship
