Humidity Sensor Switch

Model # MS-HS3-WH

Reduce moisture, mold, and mildew with a smart sensor that detects excess humidity through its patterned grille.


Run exhaust fans automatically as humidity levels rise
Never forget to turn exhaust fans on or off
Precise sensing technology accurately responds to changes in humidity
Rigorously tested for a wide range of climates and applications.
Save energy by ensuring fans run only when needed
Coordinates with Diva dimmer with Night Mode to offer controls in a consistent style

Configure

Model # MS-HS3-WH
Select Functionality
Select Control Technology
Select Finish / Colors

Product Details

Overview
Overview

The Humidity Sensor Switch provides intelligent control of exhaust fans through advanced, precise sensing technology. Fans activate automatically when humidity rises, managing excess moisture and damage from mildew and mold. While this humidity sensor works out-of-the-box for most applications, it can be adjusted for operating mode, run time, and sensitivity, if necessary, to be fine-tuned for your application. This control installs easily in 15 minutes or less and uses existing wiring. If a neutral connection is not present, the ground connection can be used.

Highlights
  • XactSense humidity sensor switch precisely detects both sudden and gradual humidity changes
  • Proven humidity sensing capabilities and default settings reduce the need for additional setup once installed.
  • Tune the control to the specific needs of the space in terms of climate and application, if necessary.
  • Light sensor prevents fan operation during nighttime hours
  • Works with 3A fan
  • 10-year warranty with product registration
What's Included

One Humidity Sensor Switch

Wall plate sold separately

Additional Model Numbers

None

Dimensions
Dimension image
Installation Details
  • If neutral connection is not present, a ground connection can be used.
  • Single pole
  • Simple 15-minute installation with existing wiring
Specifications & Documents
General Specifications

Color/Finish

Gloss White

Style & Type

Tap switch

Humidity sensor

Overall Dimensions

4.1" tall x 1.7" wide x 1.4" deep (without wall plate)

Mounting Type

In-wall

Wiring Type

Single pole

Wiring Requirements

Neutral or ground connection required

Indoor / Outdoor

Indoor

Warranty

10 years with product registration

Electrical Specifications

Voltage

120 V~ 50/60 Hz

Ratings

3 A  1/10 HP fan, 3 A combined exhaust fan and light

General Documents

Installation & Tools

See the Spec Sheet

Find Installation Guide

Use the Wiring Wizard
