Rania D2 Wall Wash Remodeler Downlight—2” Aperture
Exceptional 3-channel Natural Light in a 2-inch wall wash downlight with smooth uniform distribution for finished ceilings in remodel projects.
Configure
Product Details
Overview
With innovative 3-channel engineering, this 2-inch wall wash downlight brings Rania's Natural Light to remodeler applications. The D2 Remodeler installs directly through finished ceilings via a standard 3.125-inch cutout (4-inch for flangeless mud-in trim), delivering smooth and even illumination across walls to enhance architectural details. Its non-IC-rated housing is optimized for residential and commercial projects where ceilings have already been installed. Rania's 3-channel technology produces natural white light that surpasses conventional tunable white solutions, delivering a broader CCT range with consistent 90+ CRI rendering from 2700K to 5000K. Control the Rania D2 Remodeler with the HomeWork wireless control system to bring the outside in—capturing the full spectrum of daylight from sunrise to sunset through location-aware sun tracking.
- 3-channel light engine replicates the feeling of natural daylight more precisely than conventional 2-channel tunable white or warm-dim luminaires
- Delivers a broad range of natural white light, from incandescent glow to afternoon sun (1800K–5500K)
- 90+ CRI light renders colors, objects, and finishes vividly under both warm and cool light
- This wall wash with a 2-inch aperture provides uniform distribution of light, delivering smooth and even illumination across the wall
- Non-IC-rated downlight installs directly through finished ceilings via a standard 3.125-inch cutout (4-inch for flangeless mud-in trim), cutting demolition costs and construction delays
- Designed to work with Lutron's wireless control systems, Rania D2 Remodeler communicates with the control system via Clear Connect Type X
3-channel natural white light / 1,800K–5,500K
90+ CRI from 2,700K–5,000K / R9 >80
Native wireless control with Lutron Clear Connect Type X
- HomeWorks
Specifications & Documents
Performance Specifications
Light Engine
3-channel natural white light
CCT Range
1,800K–5,500K
Color Rendering
90+ CRI from 2700K to 5000K
R9 >80
No Vibrancy
Rated Life
50,000 hours to L70
Dimming Range
0.1%–100%
Delivered Lumens
651 lm
Beam Angles
Wall Wash
Control Specifications
Control Protocol
Wireless RF/CCX (Lutron Clear Connect-Type X)
Dimensions Specifications
Aperture Size
2 in
Cut-out Dimensions
3.13 in (79.37 mm) Flanged
4.00 in (101.6 mm) Flangeless Mud-in
2.83 in (71.88 mm) Flangeless Millwork
Ceiling Thickness
0.5–2 in (12.7–50.8 mm)
Electrical Specifications
Power Consumption
16.3 W
Voltage
120 V~ 60 Hz
Current
800 mA, 0.2 ms duration
Mechanical Specifications
Installation Options
Flanged, Flangeless Mud-in, Flangeless Millwork
Certifications Specifications
Environmental Rating
UL Damp Location/UL Wet Location available with Trim Lens
Certifications
UL, cUL, 120 V~: FCC Class B, T24 (JA8); Non-IC Rated; UL2043 and CAN/ULC-S142 Rated
Warranty
5-year fixture, LED, and dimming warranty
