Lumaris Remodeler Downlight

Model # CD4-TW

Bring intelligent, wireless lighting to new construction or remodeling projects with this two-channel, tunable white light.


Light Engine: 2-channel, tunable white light
Aperture Size: 3-inch remodeler installation
CCT Range: 1,800K–4,000K color temperature
Application: IC-rated for canless installation in insulated ceilings
Color Rendering: 90+ CRI across full range
Native control: Made to work with Lutron wireless control systems

Configure

Model # CD4-TW
Select Fixture Type
Select Brand
Select Installation Type
Select Aperture Size

Product Details

Overview
Overview

Lumaris remodeler downlights bring intelligent, wireless lighting to new construction projects. These two-channel downlights provide tunable white and warm dim light that renders objects faithfully, with a CRI rating of 90+. Control color temperature and light intensity separately or tie them together in a warm dimming curve that mimics the familiar golden look of incandescent dimming.  Available in three-inch and four-inch apertures, Lumaris remodeler downlights offer flexible placement and are built from the ground up to work with Lutron control systems.

Highlights
  • 2-channel light engine delivers high-quality, tunable white light
  • Dial color temperature between 1,800K–4,000K, from incandescent glow to afternoon sun
  • With a CRI of 90+, Lumaris renders colors and objects richly across its range
  • 4¼ to 4½-inch cutout fits standard construction with integrated housing
  • Installs into IC-rated housings, enabling direct contact with insulation
  • 3-inch aperture and ½-inch recess minimize glare and keep ceilings quiet and uncluttered
  • Add Lumaris lighting to HomeWorks and RadioRA 3 systems for seamless wireless residential spaces
Light Engine

2-channel tunable white / 1,800K–4,000K / 90+ CRI

Wireless Control

Native wireless control with Lutron Clear Connect Type X

Dimensions
cd4-tw-d
System Compatibility
  • HomeWorks QSX
  • RadioRA 3
Specifications & Documents
Performance Specifications

Light Engine

2-channel, tunable white

CCT Range

1,800K–4,000K

Color Rendering

CRI >90

Rated Life

50,000 hours to L70

Dimming Range

0.1%–100%

Delivered Lumens

800 lm

Beam Angles

N/A

Adjustable

No

Control Specifications

Control Protocol

Wireless RF/CCX (Lutron Clear Connect-Type X)

Dimensions Specifications

Aperture Size

3 in

Overall Dimensions

H 3.9 in (99.1 mm) x L 5.1 in (129.5 mm) x W 5.1 in (129.5 mm)

Cut-out Dimensions

4.25 - 4.5 in (107.9-114.3 mm)

Ceiling Thickness

1.25 in to 1.37 in (31.8 mm to 34.9 mm)

Electrical Specifications

Power Consumption

8.5 W

Voltage

120 V ~ 60 Hz

Current

0.07 A

Mechanical Specifications

Installation Options

Recessed

Type

Type IC rated and inherently protected (Housing Type)

LED, integrated (Lamp Type)

Certifications Specifications

Environmental Rating

IP20 indoor dry / damp location

Regulatory Approvals

cULus listed; FCC approved. Complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules; Industry Canada certified; California Title 24 as detailed in Reference Joint; Appendix JA8 for High Luminous Efficacy Light Sources.

Warranty

5 year fixture, LED and dimming warranty
