Lumaris Tape Light – RGB + Tunable White LED

Full-spectrum RGB color and tunable white in a 5-channel LED tape light for dynamic accent lighting that transforms spaces with both vibrant color and precision-tuned white light.


Light Engine: 5-channel RGB + tunable white light
CCT Range: 1800K-4000K (white), plus 16.7 million colors
Color Rendering: 90+ CRI (white light)
Useful Life: 50,000 hours at L70
Brightness: 200 lumens per foot (white light)
Native Control: Made to work with Lutron wireless control systems

Configure

Select Brand
Select Color Output

Product Details

Overview
Overview

Intelligent lighting starts with Lumaris, combining vibrant RGB color with tunable white light in a single tape solution. This 5-channel LED tape light offers the complete spectrum—from saturated colors for dramatic accent effects to precision-tuned tunable white light (1800K-4000K) for everyday illumination. Transform spaces with 16.7 million color options using Lutron's intuitive scene selection or app-based color controls, then transition seamlessly to high-quality white light with 90+ CRI rendering and flicker-free dimming down to 0.1%. Field-cuttable every 4 inches with pre-soldered wires for easy connection, this RGB + tunable white tape light can run up to 32.8 feet from a single Multi-Channel Wireless Controller and delivers 200 lumens per foot of tunable white illumination. And since Lumaris was designed from the start to work with Lutron's HomeWorks, RadioRA 3, Athena, and myRoom XC wireless control systems, it brings intelligence to everyday lighting—whether through automatic day-to-night transitions with RadioRA 3 or advanced sun tracking with HomeWorks.

Highlights
  • 5-channel engine produces full RGB color palette plus tunable white light (1800K-4000K) in one tape solution
  • Delivers 16.7 million colors for creative accent lighting or high-quality white light with consistent 90+ CRI
  • 200 lumens per foot of tunable white illumination suitable for both functional illumination and dramatic color effects
  • Field-cuttable every 4 inches with pre-soldered 22 AWG wires for reliable connections
  • Choose from a variety of aluminum extrusion profiles to find the best fit for your project's architectural conditions
  • Multi-Channel Wireless Controller supports up to 32.8 feet of tape
  • Designed to work with Lutron's wireless control systems via Multi-Channel Wireless Controller
Light Engine

5-channel RGB + tunable white light/ 1,800K - 4,000K (white)/ 90+ CRI

Wireless Control

Clear Connect–Type X wireless communication

Dimensions
Lumaris Tape Light – RGB + Tunable White LED - Dimensions
System Compatibility
  • HomeWorks
  • RadioRA 3
  • Athena
  • myRoom XC
Specifications & Documents
Performance Specifications

Light Engine

5-channel RGB + Tunable White Light

CCT Range

1,800K-4,000K

Saturated Colors

16.7 million colors

Color Rendering

90+ CRI from 1800K to 4000K

No Vibrancy

Rated Life

50,000 hours

Dimming Range

0.1%–100%

Delivered Lumens

200 lumens per foot

Control Specifications

Control Protocol

Wireless RF/CCX (Lutron Clear Connect-Type X)

Dimensions Specifications

Aperture Size

N/A

H x L x W

16.4 - 98.4 ft (5-30 m) long

.47 in (12 mm)

Field Cuttable to 2 in (50 mm) segments

Overall Dimensions

16.4 - 98.4 ft (5-30 m) long

.47 in (12 mm)

Field Cuttable to 2 in (50 mm) segments

Electrical Specifications

Power Consumption

96 W

Voltage

120 V~ / 277 V~ 50/60 Hz

Current

800 mA

Mechanical Specifications

Installation Options

Terminal block

Flying Leads

Certifications Specifications

Environmental Rating

cULus Listed for USA and Canada

FCC Part 15 Class B compliant

ICES-005 compliant

Certifications

Meets UL® 8750/CSA C22.2 No. 250.13-14, “Light Emitting Diode (LED) Equipment For Use in Lighting Products”

Warranty

5 year limited warranty

General Documents
Lumaris Tape Light – RGB + Tunable White LED - LU-T30-RT-IN

Lumaris Tape Light – RGB + Tunable White LED
