Lumaris Tape Light – Tunable White LED
Tunable white and warm dim in a 2-channel LED tape light delivering superior accent lighting for architectural details and ambient illumination.
Configure
Product Details
Overview
Intelligent lighting starts with Lumaris, bringing tunable white and warm dim technology to accent and cove lighting applications. This 2-channel LED tape light combines the familiarity of incandescent dimming with precise color temperature control, delivering smooth transitions from an incandescent glow to bright white (1,800K-4,000K) with flicker-free dimming down to 0.1%. With a modular three-piece design, Lumaris simplifies installation and programming compared to other DMX and 0-10V tunable white tape solutions available on the market today. Field-cuttable every 2 inches for precise installation, this 10mm wide tape installs with strong VHB adhesive backing and fits beautifully into straight and curved applications. Available in 16.4 ft and 98.4 ft reels with both plug-in and hard-wired power supplies. And since Lumaris was designed from the start to work with Lutron's HomeWorks, RadioRA 3, Athena, and myRoom XC wireless control systems, it brings intelligence to everyday lighting—whether through automatic day-to-night transitions with RadioRA 3 or advanced sun tracking with HomeWorks.
- 2-channel tunable white light feels and looks better across its range (1,800K-4,000K) with consistent 90+ CRI
- Delivers the familiarity of incandescent dimming coupled with precise color temperature control in one technology
- 200 lumens per foot of accent illumination suitable for cove lighting, under-cabinet, and architectural details
- Field-cuttable every 2 inches with strong VHB adhesive backing for flexible installation in any indoor dry/damp location
- Choose from a variety of aluminum extrusion profiles to find the best fit for your project's architectural conditions
- Modular three-piece design reduces device count over DMX solutions to simplify installation and programming
- Tunable White Controller supports up to 16.4 feet of tape and Multi-Channel Controller supports up to 49.2 feet of tape
- Designed to work with Lutron's wireless control systems via Clear Connect Type X technology
2-channel tunable white light/ 1,800K-4,000K)/90+ CRI
Clear Connect–Type X wireless communication
- HomeWorks
- RadioRA 3
- Athena
- myRoom XC
Specifications & Documents
Performance Specifications
Light Engine
2-channel tunable white
CCT Range
1,800K-4,000K
Saturated Colors
N/A
Color Rendering
90+ CRI from 1,800K to 4,000K
No Vibrancy
Rated Life
50,000 hours
Dimming Range
0.1%–100%
Delivered Lumens
200 lumens per foot
Control Specifications
Control Protocol
Wireless RF/CCX (Lutron Clear Connect-Type X)
Dimensions Specifications
Aperture Size
N/A
H x L x W
16.4 - 98.4 ft (5-30 m) long
.47 in (12 mm)
Field Cuttable to 2 in (50 mm) segments
Overall Dimensions
16.4 - 98.4 ft (5-30 m) long
.47 in (12 mm)
Field Cuttable to 2 in (50 mm) segments
Electrical Specifications
Power Consumption
96 W
Voltage
120 V~ / 277 V~ 50/60 Hz
Current
800 mA
Mechanical Specifications
Installation Options
Terminal block
Flying Leads
Certifications Specifications
Environmental Rating
cULus Listed for USA and Canada
FCC Part 15 Class B compliant
ICES-005 compliant
Certifications
Meets UL® 8750/CSA C22.2 No. 250.13-14, “Light Emitting Diode (LED) Equipment For Use in Lighting Products”
Warranty
5 year limited warranty
