Sivoia Roman Fabrication Kit – Low-Voltage Wired for 11.7 lb

Premium custom Roman shade fabrication kit powered by Roller 64 Lutron drive technology.


Width Range: 21.5"-109.5" bracket to bracket
Maximum Weight: 11.7 lbs fabric panel capacity
Sound Level: Operates at less than 35 dBA at 3ft
Power: 35V low-voltage wiring
Communication: QS wired and wireless
Fabric: Custom-fabrication with any material

Configure

Select Power Options
Select Max Weight

Product Details

Overview
Overview

The Sivoia Roman Shade Fabrication Kit with Roller 64 Lutron drive technology delivers ultra-quiet precision motorization for custom-fabricated Roman shades from 21.5 to 109.5 inches wide with fabric panels up to 11.7 pounds. This fabrication kit pairs custom material selection with precision Lutron motorization, supported by Lutron shade specialists who guide fabric selection and pleat configuration to achieve the ultimate design for any space. The Roller 64 Electronic Drive Unit controls shade movement, tracks position, and adjusts to preset positions while incorporating precision alignment technology to synchronize all shades throughout a room or home. These shades operate at less than 35 dBA at 3 feet for library-quiet environments. Backed by an 8-year limited warranty and compatible with QS wired and wireless protocols, Sivoia Roman shades unlock Natural Light Optimization technology when paired with RadioRA 3, HomeWorks, and Athena systems, tracking the sun's movement throughout the day to automatically adjust shade positions and manage glare and heat gain while preserving views and daylight.

Highlights
  • Accommodates custom-fabricated Roman shades from 21.5 to 109.5 inches wide with fabric panels up to 11.7 lbs
  • Ultra-quiet operation below 35 dBA measured 3 feet away creates library-quiet environments
  • Custom-fabrication accommodates any material, with Lutron shade specialists available to guide fabric and pleat selection
  • Precision alignment technology synchronizes all shades throughout a room or home for unified control
  • 35V low-voltage wiring simplifies installation
  • Compatible with QS wired and wireless protocols for integration with RadioRA 3, HomeWorks, myRoom XC, Quantum, Athena, and Caséta PRO systems or standalone operation
Dimensions
Sivoia Roman Fabrication Kit – Low-Voltage Wired for 11.7 lb - Dimensions
Mounting & Installation Highlights
  • Orient the EDU mounting yolk so that the drive control buttons face downward, and route the EDU cables through one of the side notches.
  • The idler is spring-loaded so you can push the tube toward it to gain clearance at the drive end. Locate the drive mounting yolk over / under the mounting tabs on the bracket as shown.
Specifications & Documents
General Specifications

Overall Dimensions

Maximum shade width: 109.5"

Power Options

35V low-voltage wiring

Control Communication

QS wired and wireless

Top treatment

Headrail not included

Weight Capacity

Up to 11.4 lb

Performance Specifications & Features

Sound Level

Ultra-quiet operation below 35 dBA measured 3 feet away creates library-quiet environments

Design Specifications

Fabric Options

Customer provided textiles

Certifications Specifications

Environmental Rating

Temperature: 32 F to 104˚ F (0 C to 40˚ C). For indoor use only. Relative Humidity: < 90% non-condensing.

Fabric Standards / Certification Options Available

PVC Free, Fire Rated, Anti-microbial Properties, GREENGUARD Certified, RoHS Compliant, Cradle to Cradle Certified, Lead Free

Regulatory Approvals

CE UL FCC

Warranty

8 years with registration
