Sivoia Roller 225 Shades – Recessed Single Pocket, 7"
Premium, high-powered low-voltage roller shade for the largest windows, configured with a 7" recessed pocket.
Configure
Product Details
Overview
Sivoia Roller 225 shades with 7-inch recessed pocket deliver maximum power for the largest windows from 31.75 to 190 inches wide, completely disappearing into deep architectural pockets designed for large-scale installations with a typical maximum shade size of 225 square feet. The substantial pocket depth conceals the high-capacity drive system while providing extensive clearance for fabric accumulation from extra-wide windows and accommodating over 600 designer fabrics—including the most substantial blackout materials. Operating at less than 38 dBA at 3 feet, these shades feature Intelligent Hembar Alignment technology that monitors shade speed hundreds of times per second to guarantee alignment within 1/8 inch as bottom bars travel smoothly even with maximum fabric loads on the widest single-shade applications. Backed by an 8-year limited warranty and compatible with most Lutron control systems, Sivoia shades unlock Natural Light Optimization technology when paired with RadioRA 3, HomeWorks, and Athena systems, tracking the sun's movement throughout the day to automatically adjust shade positions and manage glare and heat gain while preserving views and daylight.
- Supports typical maximum shade size of 225 square feet for windows from 31.75 to 190 inches wide, with precise sizing dependent on fabric and height specifications
- Patented Intelligent Hembar Alignment technology monitors shade speed hundreds of times per second to maintain alignment within 1/8 inch across all shades
- Quiet operation below 38 dBA measured 3 feet away despite high power capacity
- 35V low-voltage wiring simplifies installation
- Compatible with QS wired and wireless protocols for integration with RadioRA 3, HomeWorks, myRoom XC, Quantum, Athena, and Caseta PRO systems or standalone operation
- 7-inch pocket conceals up to 225 square feet of fabric from 600+ designer options
Low-voltage Class 2, 35 V power supply required (Individual plug-in power supplies, junction box power supplies, or centralized power panel options available)
Supports typical maximum shade size of 225 square feet for windows from 31.75 to 190 inches wide, with precise sizing dependent on fabric and height specifications
- The shade system must be mounted to blocking or other suitable structural material.
- Depending on window dimensions, brackets can be mounted in a pocket, inside the window frame, or outside the window frame.
- EDU can be specified on the left or right side of the shade.
- Shade can be regular or reverse roll.
Specifications & Documents
General Specifications
Overall Dimensions
Width (Single Panel): 31.75"-190"—varies by fabric and height
Power Options
35V Low Voltage
Control Communication
Lutron QS Wired Lutron QS Wireless (ClearConnect Type A RF technology): 30ft wireless control range
Top treatment
Recessed Metal Pocket 7" w x 7" h
Performance Specifications & Features
Sound Level
Operates at less than 38 dBA at 3ft
Speed
Bottom bar speed: 3.6 in/sec
Precision Control
Intelligent Hembar Alignment (IHA): Shades remain within 1⁄8 in (3 mm) alignment when in motion or stopped
Coupling
No
Natural Light Optimization
Yes, available with HomeWorks, RadioRA 3, Caseta, Athena
Design Specifications
Fabric Options
Sheer, Translucent, Blackout
Fabric Collections
The Classico Collection, The Gallery Collection, The Atelier Collection, The Commercial Collection
Mounting Options
Wall, Ceiling, or Jamb
Hembar Options
Designer Bottom Bar, Sealed Bottom Bar, Half-wrap Architectural Bottom Bar
Finishes
Pocket Metal Finishes: White, Black, Bronze, Silver, custom color
Certifications Specifications
Environmental Rating
Temperature: 32 F to 104˚ F (0 C to 40˚ C). For indoor use only. Relative Humidity: < 90% non-condensing.
Fabric Standards / Certification Options Available
PVC Free, Fire Rated, Anti-microbial Properties, GREENGUARD Certified, RoHS Compliant, Cradle to Cradle Certified, Lead Free
Environmental Standards / Certifications
Lutron shading solutions and controls can contribute to achieving certifications such as LEED, WELL, and BREEAM.
Regulatory Approvals
cULus listed (E135084) FCC (USA) IC (Canada) CFT (Mexico) CE Mark (European Union) FCC Certified (Hong Kong) UKCA (United Kingdom) NCC (Taiwan) TRA (United Arab Emirates)
Warranty
Eight Year Limited Warranty
