Sivoia Roller 300 Shades – Dual Pocket, 7" x 11"
Premium, high-powered low-voltage roller shade for driving multiple large shades, configured with a dual 7"x11" recessed pocket.
Configure
Product Details
Overview
Sivoia Roller 300 dual pocket systems provide maximum-capacity light management through two independent shade layers within a single 7"x11" architectural opening that completely conceals both roller mechanisms when raised, with each layer capable of driving up to six coupled panels with a typical maximum shade size of 300 square feet per layer. This dual configuration pairs sheer fabrics for daytime privacy with blackout materials for room darkening, both powered by heavy-duty drives while drawing from over 600 material options to create custom light-filtering combinations across expansive facades. For configurations where wider spans could cause fabric deflection, Width Integrated Deflection Reduction (WIDR) technology uses carbon fiber tubes to prevent sagging and rippling by maintaining consistent fabric tension, with the Lutron Quoting and Ordering Tool precisely calculating when WIDR is required. Both shade layers operate at less than 50 dBA at 3 feet while Intelligent Hembar Alignment technology monitors shade speed hundreds of times per second to guarantee alignment within 1/8 inch, whether operating together or separately across multiple coupled panels. Backed by an 8-year limited warranty and compatible with most Lutron control systems, Sivoia shades unlock Natural Light Optimization technology when paired with RadioRA 3, HomeWorks, and Athena systems, tracking the sun's movement throughout the day to automatically adjust shade positions and manage glare and heat gain while preserving views and daylight.
- Supports typical maximum shade size of 300 square feet per layer for individual shades from 26.5 to 176 inches wide with coupling for up to 6 panels per layer, with precise sizing dependent on fabric and height specifications
- Patented Intelligent Hembar Alignment technology monitors shade speed hundreds of times per second to maintain alignment within 1/8 inch across all shades
- Quiet operation below 50 dBA measured 3 feet away for both shade layers simultaneously
- 35V low-voltage wiring required for each shade individually
- Compatible with QS wired and wireless protocols for integration with RadioRA 3, HomeWorks, myRoom XC, Quantum, and Athena systems
- Dual drives handle 300 square feet per layer from 600+ fabric options across 6 coupled dual roller shades
- The Lutron Quoting and Ordering Tool automatically specifies carbon fiber WIDR tubes when shade width and fabric combinations require deflection prevention
Low-voltage Class 2, 35 V power supply required (Individual plug-in power supplies, junction box power supplies, or centralized power panel options available)
Supports typical maximum shade size of 300 square feet per motor for windows from 26.5 to 176 inches wide with coupling capability for up to 6 panels per layer, with precise sizing dependent on fabric and height specifications
- The shade system must be mounted to blocking or other suitable structural material.
- Depending on window dimensions, brackets can be mounted in a pocket, inside the window frame, or outside the window frame.
- EDU can be specified on the left or right side of the shade.
- Shade can be regular or reverse roll.
Specifications & Documents
General Specifications
Overall Dimensions
Width (Single Panel): 26.5"-176"—varies by fabric and height
Power Options
35V Low Voltage
Control Communication
Lutron QS Wired Lutron QS Wireless (ClearConnect Type A RF technology): 30ft wireless control range
Top treatment
Recessed Metal Pocket 7" w x 11" h
Performance Specifications & Features
Sound Level
Operates at less than 50 dBA at 3ft
Speed
Bottom bar speed: 3.6 in/sec
Precision Control
Intelligent Hembar Alignment (IHA): Shades remain within 1⁄8 in (3 mm) alignment when in motion or stopped
Coupling
Yes, up to 6 panels
Natural Light Optimization
Yes, available with HomeWorks, RadioRA 3, Caseta, Athena
Cable Guided
Design Specifications
Fabric Options
Sheer, Translucent, Blackout
Fabric Collections
The Classico Collection, The Gallery Collection, The Atelier Collection, The Commercial Collection
Mounting Options
Wall, Ceiling, or Jamb
Hembar Options
Designer Bottom Bar Sealed Bottom Bar Half-wrap Architectural Bottom Bar Exposed Architectural Bottom Bar 1 in (25mm) Exposed Bottom Bar
Finishes
Pocket Metal Finishes: White, Black, Bronze, Silver, custom color
Certifications Specifications
Environmental Rating
Temperature: 32 F to 104˚ F (0 C to 40˚ C). For indoor use only. Relative Humidity: < 90% non-condensing.
Fabric Standards / Certification Options Available
PVC Free, Fire Rated, Anti-microbial Properties, GREENGUARD Certified, RoHS Compliant, Cradle to Cradle Certified, Lead Free
Environmental Standards / Certifications
Lutron shading solutions and controls can contribute to achieving certifications such as LEED, WELL, and BREEAM.
Regulatory Approvals
cULus listed (E135084) FCC (USA) IC (Canada) CFT (Mexico) CE Mark (European Union) FCC Certified (Hong Kong) UKCA (United Kingdom) NCC (Taiwan) TRA (United Arab Emirates)
Warranty
Eight Year Limited Warranty
