Sivoia Roller 300 Clerestory Shades – Recessed Single Pocket, 7"

Premium, high-powered low-voltage roller shade for the tallest windows, configured with reinforced components for 20-30' heights.


Width (Single Panel): 26.5"-176"—varies by fabric and height
Mounting Heights: Designed for installations 20' to 30'
Sound Level: Operates at less than 50 dBA at 3ft
Power: 35V low-voltage wiring
Communication: QS wired and wireless
Fabric Options: 500+ designer fabrics available

Configure

Select Top Treatment
Select Top Treatment Size
Select Power Options
Select Drive Type

Product Details

Overview
Overview

Sivoia Roller 300 Clerestory shades with 7-inch recessed pocket are specifically engineered for installations at heights between 20 and 30 feet, featuring reinforced components designed to withstand the unique stresses of elevated mounting positions. The specialized configuration includes a reengineered tube, enhanced bracketry system, and reinforced brackets that ensure reliable operation in multi-story applications where standard shades require additional security and stability while working with a curated selection of fabrics specifically tested for clerestory installations. Required battens on shades over 20 feet maintain finished shade aesthetics and ensure proper roll-up while preventing fabric billowing. While mounted at significant heights, these shades operate at less than 50 dBA at 3 feet and feature Intelligent Hembar Alignment technology that monitors shade speed hundreds of times per second to guarantee alignment within 1/8 inch during motion and at all resting positions. The 7-inch pocket accommodates the reinforced mechanical systems required for elevated installations. Backed by an 8-year limited warranty and compatible with most Lutron control systems, Sivoia shades unlock Natural Light Optimization technology when paired with HomeWorks and RadioRa 3 systems and Athena Shade Automation Software for Athena system, tracking the sun's movement throughout the day to automatically adjust shade positions and manage glare and heat gain while preserving views and daylight. © James Steinkamp Photography

Highlights
  • Engineered specifically for elevated mounting heights between 20 and 30 feet with widths from 26.5 to 176 inches, with precise sizing dependent on fabric choice and window height requirements
  • Patented Intelligent Hembar Alignment technology monitors shade speed hundreds of times per second to maintain alignment within 1/8 inch across all shades
  • Quiet operation below 50 dBA measured 3 feet away despite elevated mounting position
  • 35V low-voltage wiring for reliable power delivery at height
  • Compatible with QS wired and wireless protocols for integration with RadioRA 3, HomeWorks, myRoom XC, Quantum, Athena, and Caseta PRO systems or standalone operation
  • Limited fabric selection with required battens over 20 feet to maintain finished shade aesthetics and ensure proper roll-up at height
Power Source

Low-voltage Class 2, 35 V power supply required (Individual plug-in power supplies, junction box power supplies, or centralized power panel options available)

Minimum Width & Maximum Width

Engineered specifically for elevated mounting heights between 20 and 30 feet with widths from 26.5 to 176 inches, with precise sizing dependent on fabric choice and window height requirements

Dimensions
Sivoia Roller 300 Clerestory Shades – Recessed Single Pocket, 7" - Dimensions
Mounting & Installation Highlights
  • The shade system must be mounted to blocking or other suitable structural material.
  • Depending on window dimensions, brackets can be mounted in a pocket, inside the window frame, or outside the window frame.
  • EDU can be specified on the left or right side of the shade.
  • Shade can be regular or reverse roll.
Specifications & Documents
General Specifications

Overall Dimensions

Width (Single Panel): 26.5"-176"—varies by fabric and height

Power Options

35V Low Voltage

Control Communication

Lutron QS Wired
Lutron QS Wireless (ClearConnect Type A RF technology): 30ft wireless control range

Top treatment

Recessed Metal Pocket 7" w x 7" h

Performance Specifications & Features

Sound Level

Operates at less than 50 dBA at 3ft

Speed

Bottom bar speed: 3.6 in/sec

Precision Control

Intelligent Hembar Alignment (IHA): Shades remain within 1⁄8 in (3 mm) alignment when in motion or stopped

Coupling

Yes, up to 6 panels

Natural Light Optimization

Yes, available with HomeWorks and RadioRA 3 and Athena Shade Automation Software for Athena.

Design Specifications

Fabric Options

Sheer, Translucent, Blackout

Fabric Collections

The Classico Collection, The Gallery Collection, The Atelier Collection, The Commercial Collection

Mounting Options

Wall, Ceiling, or Jamb

Hembar Options

Designer Bottom Bar, Sealed Bottom Bar, Half-wrap Architectural Bottom Bar

Finishes

Pocket Metal Finishes: White, Black, Bronze, Silver, custom color

Certifications Specifications

Environmental Rating

Temperature: 32 F to 104˚ F (0 C to 40˚ C). For indoor use only. Relative Humidity: < 90% non-condensing.

Fabric Standards / Certification Options Available

PVC Free, Fire Rated, Anti-microbial Properties, GREENGUARD Certified, RoHS Compliant, Cradle to Cradle Certified, Lead Free

Environmental Standards / Certifications

Lutron shading solutions and controls can contribute to achieving certifications such as LEED, WELL, and BREEAM.

Regulatory Approvals

cULus listed (E135084)
FCC (USA)
IC (Canada)
CFT (Mexico)
CE Mark (European Union)
FCC Certified (Hong Kong)
UKCA (United Kingdom)
NCC (Taiwan)
TRA (United Arab Emirates)

Warranty

Eight Year Limited Warranty

General Documents

Installation & Tools

View the Spec Sheet

Find Installation Guide

Explore Residential Shades Brochure

Read the Warranty
