Sivoia Roller 64 Shades – Dual Pocket, 5.5" x 7.5"
Premium low-voltage roller shade for medium-sized windows, configured without top treatment for site-built valances or pockets.
Configure
Product Details
Overview
Sivoia Roller 64 dual pocket systems enable sophisticated daylight control through two independent shades within a single 5.5"x7.5" recessed pocket that completely conceals both roller mechanisms when raised, perfect for windows up to 12 feet wide with a typical maximum combined shade size of 144 square feet. This dual configuration allows pairing of sheer fabrics for view preservation and daytime privacy with room-darkening materials for complete light control, all within a single architectural opening while drawing from over 600 fabric options. For configurations where wider spans could cause fabric deflection, Width Integrated Deflection Reduction (WIDR) technology uses carbon fiber tubes to prevent sagging and rippling by maintaining consistent fabric tension, with the Lutron Quoting and Ordering Tool precisely calculating when WIDR is required. Both shades operate independently at an ultra-quiet 35 dBA at 3 feet, with each shade incorporating Intelligent Hembar Alignment technology that monitors shade speed hundreds of times per second to guarantee alignment within 1/8 inch, whether operating together or separately. Backed by an 8-year limited warranty and compatible with most Lutron control systems, Sivoia shades unlock Natural Light Optimization technology when paired with HomeWorks and RadioRa 3 systems and Athena Shade Automation Software for Athena system, tracking the sun's movement throughout the day to automatically adjust shade positions and manage glare and heat gain while preserving views and daylight.
- Supports typical maximum combined shade size of 144 square feet for windows from 17.5 to 144 inches wide with dual-shade configuration, with precise sizing dependent on fabric and height specifications
- Patented Intelligent Hembar Alignment technology monitors shade speed hundreds of times per second to maintain alignment within 1/8 inch across all shades
- Ultra-quiet operation below 35 dBA measured 3 feet away for both shades simultaneously
- 35V low-voltage wiring required for each shade individually
- Compatible with QS wired and wireless protocols for integration with RadioRA 3, HomeWorks, myRoom XC, Quantum, and Athena systems
- Layer sheer and blackout fabrics from 600+ options to create complete daylight control
- The Lutron Quoting and Ordering Tool automatically specifies carbon fiber WIDR tubes when shade width and fabric combinations require deflection prevention
Low-voltage Class 2, 35 V power supply required (Individual plug-in power supplies, junction box power supplies, or centralized power panel options available)
Supports typical maximum combined shade size of 144 square feet for windows from 17.5 to 144 inches wide with dual-shade configuration, with precise sizing dependent on fabric and height specifications
- The shade system must be mounted to blocking or other suitable structural material.
- Depending on window dimensions, brackets can be mounted in a pocket, inside the window frame, or outside the window frame.
- EDU can be specified on the left or right side of the shade.
- Shade can be regular or reverse roll.
Specifications & Documents
General Specifications
Overall Dimensions
Width (Single Panel): 17.5"-144"—varies by fabric and height
Power Options
35V Low Voltage
Control Communication
Lutron QS Wired
Lutron QS Wireless (ClearConnect Type A RF technology): 30ft wireless control range
Top treatment
Recessed Metal Pocket 5.5" w x 7.5" h
Performance Specifications & Features
Sound Level
Operates at less than 35 dBA at 3ft
Speed
Bottom bar speed: 3.6 in/sec
Precision Control
Intelligent Hembar Alignment (IHA): Shades remain within 1⁄8 in (3 mm) alignment when in motion or stopped
Coupling
No
Natural Light Optimization
Yes, available with HomeWorks and RadioRA 3 and Athena Shade Automation Software for Athena.
Design Specifications
Fabric Options
Sheer, Translucent, Blackout
Fabric Collections
The Classico Collection, The Gallery Collection, The Atelier Collection, The Commercial Collection
Mounting Options
Wall, Ceiling, or Jamb
Hembar Options
Designer Bottom Bar, Sealed Bottom Bar, Half-wrap Architectural Bottom Bar
Finishes
Pocket Metal Finishes: White, Black, Bronze, Silver, custom color
Certifications Specifications
Environmental Rating
Temperature: 32 F to 104˚ F (0 C to 40˚ C). For indoor use only. Relative Humidity: < 90% non-condensing.
Fabric Standards / Certification Options Available
PVC Free, Fire Rated, Anti-microbial Properties, GREENGUARD Certified, RoHS Compliant, Cradle to Cradle Certified, Lead Free
Environmental Standards / Certifications
Lutron shading solutions and controls can contribute to achieving certifications such as LEED, WELL, and BREEAM.
Regulatory Approvals
cULus listed (E135084)
FCC (USA)
IC (Canada)
CFT (Mexico)
CE Mark (European Union)
FCC Certified (Hong Kong)
UKCA (United Kingdom)
NCC (Taiwan)
TRA (United Arab Emirates)
Warranty
Eight Year Limited Warranty
